MRS.T SOFT SM
MRS. T SOFT SM is one of the original members of the DARKON family, combining elegant proportions with a beautifully refined soft-end aesthetic. Featuring seamless glowing end caps, signature shadow-line detailing, and an extensive range of lighting options, it delivers a sophisticated architectural solution that is both timeless and highly versatile.
Models

- Lens
- OPAL
- Direction
- Direct
- Output Type
- High Output
- Milliamp
- 200 mA
- Watts
- 9.7 W
- Delivered Lumens
- 1042 lm
- Efficacy
- 107.4 lm/W
- Colour Temperature (CCT)
- 4000K
- CRI
- 90
- Lifetime
- 72,000h @ L80B10
Photometric Files
Design Features
Screwless Endcaps
Dot free homogeneous illumination
Multiple Snap Fit Lens Options
Multiple fixed output options
Install Features
Project specific labelling referencing type numbers
Supplied 100% pre-built
Detailed shop drawings
Plug and Play wire looms
Welded mitre joins eliminate light bleed
Snap fit gear tray with integrated driver
Sprung loaded control joints
Gallery
Related Projects
Available Finishes
Recommended Applications
Designer Recommendations
Technical Details
Physical Dimensions
- Width
- 100mm
- Height
- 127mm
- Weight
- 5.4kg/m
Construction & Mounting
- Materials
- Acrylic, Aluminium
- Shape
- Linear
- Mounting
- Surface Mounted
- Build Options
- Angular Linear Shapes
- Curved Fixed Radii Shapes
Optics
- Optics
- Diffuser, Combination Lens
- Light Distribution
- Deglaring, Narrow, Asymmetric, Opal
LED
- CCT
- 4000K, Tunable White, 2700K, 3000K, 3500K
- CRI
- 90
- LED Output
- 422.5–3506.7lm
- LED Power
- 6–34.5W
- LED Current
- 150mA, 200mA, 250mA, 300mA, 350mA, 400mA, 450mA, 500mA, 550mA, 600mA, 650mA
- Output Type
- High Output, High Efficiency
- LED Type
- SMD
- LED Model
- LLE 24x560mm 2400lm 940 HV ADV6, LLE 24x560mm 1300lm 940 HV ADV6, LLE 24x280mm 1100lm 927-965 LV PRE4, LLE 24x560mm 1300lm 927 HV ADV6, LLE 24x560mm 1300lm 930 HV ADV6, LLE 24x560mm 1300lm 935 HV ADV6, LLE 24x560mm 2400lm 935 HV ADV6, LLE 24x560mm 2400lm 927 HV ADV6, LLE 24x560mm 2400lm 930 HV ADV6
- Lifetime
- 72,000h @ L80B10
- Colour Consistency
- SDCM 3
- Zhaga
- Yes
Electrical & Driver
- Dimming
- DALI
- Driver
- Tridonic
- Driver Model
- LC 35/150-700/54 o4a NF h16 EXC4, LC 90/200-800/230 o4a NF h16 EXC4, LCA 50W 350-1050mA DT8 lp PRE
- Insulation Class
- Class I (Earthing)
- Cable Type
- 5 Core Flex 24/.2 (0.75mm², 7.5A) Copper, 3 Core Flex 24/.2 (0.75mm², 7.5A) Copper, 1 Core Solid V90HT (0.8mm²) Copper
- Flicker Free Driver
- Yes
Ratings & Compliance
- IP Rating
- IP22
- Standards
- AS/NZS 60598.2.1
- AS/NZS 60598.1
- AS/NZS 3000
- Compliance Reports
- LM-80LM-79
- Warranty
- Product - 10 Years (Extended)
Overview
MRS. T SOFT SM holds a special place in the DARKON story. Evolving from the original MR. T direct/indirect profile, she brought a softer and more refined personality to the family. While MR. T was the hardworking tradesman on the factory floor, MRS. T introduced elegance, versatility, and attention to detail, helping establish the design principles that continue to define the DARKON range today. Over time, her wardrobe has grown considerably. What began as a simple profile has evolved into a comprehensive architectural lighting platform, with options including downlights, emergency lighting, decorative laminates, and a variety of optical systems to suit almost any application. Yet despite these additions, the essence of MRS. T remains unchanged: elegant, adaptable, and effortlessly sophisticated. The SOFT version introduces a beautifully sculptured curved end cap that reduces hard edges and creates a calmer architectural form. Designed to complement contemporary interiors, the soft radius transitions naturally into the illuminated lens, producing a seamless glowing appearance that feels both refined and welcoming. Manufactured through a combination of precision aluminium extrusion, advanced CNC machining, and laser welding, MRS. T SOFT SM achieves a level of finish rarely seen within architectural lighting. The spring-loaded end cap system allows for lens expansion while maintaining clean lines, while DARKON's overlapping join technology eliminates light bleed and preserves a continuous illuminated appearance throughout the luminaire. Complete with the signature shadow-line detail found across the DARKON surface-mounted and suspended ranges, MRS. T SOFT SM is a lighting solution that balances engineering precision with architectural elegance. Beautiful, versatile, and timeless, she remains one of the true icons of the DARKON collection.
Extending one of the original profile offerings the MR T direct indirect came Mrs. T. the Mr T was a work man, out in the shed on the tools building lights. Mrs. T was in the office attending to enquires and doing the paperwork. Combined the 2 of them were the original founders of the DARKON range. As the family grew in size so did MRS.T’s wardrobe. He expanded offering includes downlights, emergency lights, laminates and a variety of lenses to suit any dinner occasion! She is the princess of the DARKON range.
