HIP H LP RADII RING SUS
HIP H LP RADII RING SUS extends the clean architectural aesthetic of the HIP H LP family into a striking circular form. Featuring DARKON's signature shadow-line detailing and direct/indirect illumination, the RADII RING delivers a seamless appearance, exceptional visual comfort, and scalable ring diameters for feature lighting applications.
Downloads
Design Features
Up to 112 exit lumens per system watt
Complies with AS/NZS 60598.2.1
Dot free homogeneous illumination
90+ colour rendering, 80+ available upon request
High colour tolerance - MacAdam 3
L80 / F10 = 72,000 hours @ 450mA / 75°C TA
Multiple fixed output options
Custom sizes available with tooling fee
Install Features
Project specific labelling referencing type numbers
Supplied 100% pre-built
Detailed shop drawings
Plug and Play wire looms
Available Finishes
Recommended Applications
Designer Recommendations
Technical Details
Physical Dimensions
- Width
- 69mm
- Height
- 113mm
- Diameter Options
- 805, 1160, 1516, 1872
Construction & Mounting
- Materials
- Acrylic, Aluminium
- Shape
- Linear, Round
- Mounting
- Suspended
- Suspension
- Rod Custom Length, Seismic, Wire 2m, Wire 4m
- Build Options
- Curved Fixed Radii Shapes
Optics
- Optics
- Diffuser
- Light Distribution
- Direct & Indirect
Electrical & Driver
- Insulation Class
- Class I (Earthing)
- Cable Type
- 5 Core Flex 24/.2 (0.75mm², 7.5A) Copper, 3 Core Flex 24/.2 (0.75mm², 7.5A) Copper
Ratings & Compliance
- IP Rating
- IP22
- Standards
- AS/NZS 60598.2.1
- AS/NZS 60598.1
- AS/NZS 3000
- Compliance Reports
- LM-79
- Warranty
- Product - 10 Years (Extended)
Overview
HIP H LP RADII RING SUS represents the natural evolution of the highly successful HIP H LP suspended family, transforming its refined low-profile aesthetic into a bold circular architectural statement. Retaining the distinctive shadow-line detailing that defines DARKON's suspended luminaires, RADII RING delivers the same elegant appearance and visual comfort in a striking ring format. Designed to enhance modern commercial, workplace, hospitality, and public environments, the luminaire combines direct and indirect illumination to provide both functional task lighting and soft ceiling illumination. The result is a balanced and comfortable lighting experience that enhances the perception of space while creating a strong architectural feature. For diameters up to 2.2 metres, RADII RING can be manufactured as a single-piece welded construction, creating a flawless seamless ring with no visible joints. For larger diameters, DARKON's patented self-locking overlap joining system allows rings of virtually any size to be produced while guaranteeing a continuous illuminated appearance without light bleed at the joins. The combination of precision manufacturing, low-profile proportions, and uninterrupted circular geometry creates a luminaire that appears effortless despite its sophisticated engineering. Whether used as a standalone centrepiece or as part of a larger architectural composition, HIP H LP RADII RING SUS delivers exceptional aesthetics, visual comfort, and installation flexibility. Combining elegant form, innovative engineering, and seamless illumination, HIP H LP RADII RING SUS offers a premium circular lighting solution that perfectly complements the broader HIP H LP family.
