DARKON Architectural Lighting
DEEPER-DOWN-LED-GEN2
1 / 2

DEEPER DOWN REC SLA

LED COB
AUSTRALIAN MADE
RCM
IP22

Deep Down has a recessed lamp for low glare applications and minimal trim for a trim-less appearance. The deep housing remains in the plaster board ceiling whilst the internal assembly clips out for easy maintenance.

Enquire Now

Downloads

Design Features

  • High colour tolerance - MacAdam 3

  • Complies with AS/NZS 60598.2.1

  • 90+ colour rendering

  • Minimal trim for a ‘trim-less’ appearance

  • 104 lumens per watt (lamp flux)

  • L80 / B10 = 25,000 hours @ 250mA / 75°C TP (8.8W)

  • L80 / B10 = 50,000 hours @ 350mA / 75°C TP (12.2W)

  • Extra recessed lamp for low glare applications

  • 20° gimbal inclination

  • 360° gimbal rotation

  • Universal MR16 lamp mounting

Install Features

  • Project specific labelling referencing type numbers

  • Supplied 100% pre-built

  • Easy to follow install guide

  • Removable internal assembly for easy maintenance

  • Standard hole saw cut out

  • Spring clip mounting

Technical Details

Construction & Mounting

Mounting
Recessed

Ratings & Compliance

IP Rating
IP22
