SUPER MINI EDGE
1 / 2

SUPER MINI EDGE REC

LED FLEXIBLE
AUSTRALIAN MADE
RCM
IP22

SUPER MINI EDGE REC is a trimless recessed perimeter lighting system featuring DARKON's (IES) award-winning Super Mini Grazer technology. Delivering functional wall-grazing illumination while accommodating architectural finishes up to 20mm thick, it provides a minimalist alternative to traditional cove and pelmet lighting details, seamlessly integrating light, shadow-line detailing and wall finishes into a single architectural feature.

Read more about SUPER MINI EDGE REC

Design Features


  • Dot free homogeneous illumination

  • High colour tolerance - MacAdam 3

  • Complies with AS/NZS 60598.2.1

  • 90+ colour rendering

  • L70 = 54,000 hours @ 25°C TA

Install Features


  • Project specific labelling referencing type numbers

  • Detailed shop drawings

  • Customised to room size on site

Related Projects


Recommended Applications


Primary Industry
Spaces
Health
Hospitals, Aged Care, Medical Centre, Laboratory
Education
School, University, Childcare, TAFE, Auditorium, Theatre
Hospitality
Hotel, Bar, Restaurant, Cafe
Office / Work Space
Fit Out, End of Trip, Lobby, Amenities
Residential
Multi Residential, Private Residential, Student Accommodation
Retail
Shopping Centre, Fashion

Designer Recommendations

BathroomKitchenHallwayFoyerLiving RoomBedroomDiningStudyCorridorOfficeMeeting RoomReceptionLobbyBreakout SpaceRestaurantCafeBarHotel RoomFeature Wall

Technical Details


Physical Dimensions

Width
46mm
Height
61mm

Construction & Mounting

Shape
Linear, Micro Linear
Mounting
Recessed
Build Options
Angular Linear Shapes
Accessories
Illuminated Joins

Ratings & Compliance

IP Rating
IP22

Overview


SUPER MINI EDGE REC is a trimless recessed perimeter lighting system designed to seamlessly integrate lighting, shadow-line detailing and architectural finishes into a single minimalist feature. Developed to complement modern plaster shadow-line details, the profile allows illuminated and non-illuminated sections to coexist within the same perimeter treatment, giving architects and designers the flexibility to create continuous shadow-line details with selectively illuminated zones where required. Unlike conventional cove lighting, which often creates a harsh line of brightness at the wall-to-ceiling junction, SUPER MINI EDGE REC incorporates DARKON's (IES) award-winning Super Mini Grazer light source, directing illumination down the wall surface rather than into the ceiling corner. This unique approach delivers both functional ambient illumination and a sophisticated wall-grazing effect, enhancing texture, materiality and architectural finishes while creating a softer, more visually comfortable environment. The result is a perimeter lighting solution that combines architectural feature lighting with practical room illumination without the bulk, depth and construction costs typically associated with traditional pelmet details. The profile fixes directly to the wall framing, allowing the plasterboard ceiling to terminate cleanly against the fitting to create a truly trimless appearance. Designed as a versatile architectural platform, SUPER MINI EDGE REC can accommodate wall finishes extending directly into the profile, including painted plasterboard, timber veneers, decorative panels and natural stone cladding up to 20mm thick. This enables lighting and wall treatments to become one integrated architectural detail. Perfectly suited to residential projects incorporating ceiling fans, commercial corridors, hotel suites and budget-conscious interiors where a traditional pelmet detail may be impractical, SUPER MINI EDGE REC delivers a level of architectural integration rarely seen in the market. By combining shadow-line detailing, wall grazing and functional illumination within a compact recessed profile, it offers a unique alternative to conventional cove and pelmet lighting systems.

Enquire About SUPER MINI EDGE REC

Interested in this product? Send us your details and our team will get back to you with pricing, lead times, and specifications.
