ONETRACK
AUSTRALIAN MADE
RCM
10 YEARS
IP22
A.A.G. Stucchi OneTrack® system is a 3 phase mixed system with two additional conductors intended to manage a general data signal (for example dali, dmx, etc.). It's universal 6 circuit design caters to a wide range of compatibility between both 3 circuit and 6 circuit track adaptors. Many different configurations can be achieved through the myriad of connectors, ranging from simple straight connectors to ‘X’ and even adjustable. OneTrack can be both SUSPENDED and SURFACE MOUNTED.
Design Features
Universal 6 circuit track
3 phase + 2 data + 1 neutral mixed system
Compatible with 6 circuit adaptors
Compatible with 3 circuit adaptors
Suitable for Phase / DALI / DMX / Casambi / Switch dim
Surface mounted or suspended
Customisable shapes with L / T / X connectors
900mm fixing spacing supports 25kg
450mm fixing spacing supports 50kg
Install Features
Project specific labelling referencing type numbers
Can be cut on site, note proprietary conduction snipping tool required.
Related Products
Technical Details
Construction & Mounting
- Mounting
- Suspended
Ratings & Compliance
- IP Rating
- IP22
- Warranty
- Product - 5 Years
- Product - 10 Years (Extended)
