MRS.T-G SUS

AUSTRALIAN MADE
RCM
10 YEARS
IP22
ASYMMETRIC
OPAL
DEGLARING

MRS.T-G SUS combines a 90mm direct-light lens with an integrated Grazer uplight to deliver balanced direct and indirect illumination in a visually striking suspended profile. An optional batwing uplight optic spreads light across the ceiling to improve uniformity, reduce hot spots and increase luminaire spacing, while DARKON's configurable LED platform provides exceptional flexibility for architectural lighting applications.

Read more about MRS.T-G SUS

Design Features


  • L70 / B10 @ 123,000 hours @ 250mA/ 25°C TA

  • Screwless Endcaps

  • Dot free homogeneous illumination

  • Small colour tolerance Macadam 3

  • L90 / B10 @ 42,000 hours @ 250mA /25°C TA

  • Zhaga compliant

  • 80+ or 90+ colour rendering

  • High exit lumens per watt

  • Multiple fixed output options

  • Multiple Snap Fit Lens Options

Install Features


  • Project specific labelling referencing type numbers

  • Supplied 100% pre-built

  • Detailed shop drawings

  • Plug and Play wire looms

  • Welded mitre joins eliminate light bleed

  • Snap fit gear tray with integrated driver

  • Sprung loaded control joints

Related Projects


Recommended Applications


Primary Industry
Spaces
Health
Hospitals, Aged Care, Medical Centre, Laboratory
Education
School, University, Childcare, TAFE, Auditorium, Theatre
Hospitality
Hotel, Bar, Restaurant, Cafe
Office / Work Space
Fit Out, End of Trip, Lobby, Amenities
Residential
Multi Residential, Private Residential, Student Accommodation
Retail
Shopping Centre, Supermarket, Fashion

Designer Recommendations

KitchenDiningOfficeMeeting RoomReceptionLobbyBreakout SpaceRestaurantCafeBarHotel RoomTask Lighting

Technical Details


Physical Dimensions

Width
100mm
Height
127mm
Weight
6.5kg/m

Construction & Mounting

Shape
Linear
Mounting
Suspended
Suspension
Wire Custom Length, Rod Custom Length, Seismic, Wire 2m, Wire 4m
Build Options
Angular Linear Shapes
Accessories
  • Mitre Join - Welded
  • T Intersection - Bolted
  • Illuminated Joins

Optics

Light Distribution
Asymmetric, Opal, Deglaring

Ratings & Compliance

IP Rating
IP22
Warranty
  • Product - 5 Years
  • Product - 10 Years (Extended)

Overview


MRS.T-G SUS is a suspended architectural profile designed to deliver both direct and indirect illumination while maintaining the strong visual presence and versatility of the T Series family. At its core is a 90mm combination lens for downward illumination, complemented by an integrated Grazer optic within the upper section of the profile to provide controlled uplight and enhanced spatial brightness. Together, these optical elements create a balanced lighting solution that is equally suited to feature spaces, workplaces and commercial interiors. Measuring 100mm wide by 127mm high, MRS.T-G SUS is built around a configurable LED light tray that allows specifiers to tailor the luminaire to project-specific requirements. The system accommodates multiple LED options, emergency lighting modules and downlights, while the integrated Grazer uplight delivers soft, indirect illumination to ceilings and architectural surfaces. For installations where the luminaire is suspended close to the ceiling, an optional batwing optic is available, distributing light laterally across the ceiling plane to eliminate hot spots directly above the fitting. This wider distribution improves ceiling uniformity and can increase fitting spacing, helping to achieve a more consistent indirect lighting effect across the space. Combined with DARKON's signature shadow-line detail, MRS.T-G SUS offers architects and lighting designers a highly adaptable suspended solution that balances performance, visual comfort and refined aesthetics.
