BARREL

BARREL is a 100% Australian made track-mounted spotlight, with a range of tool-free interchangeable optical control accessories designed to accommodate all lighting design applications. With a lumen output of 1287, this powerful yet elegant architectural luminaire has a Tridonic LED driver located in the track adaptor, delivering superior thermal management and a 5-year warranty. Manufactured locally to order, BARREL can be customised on request to support any specified powder coat finish desired.

Materials
Extruded and CNC machined aluminium tube
Finish
White / Black powdercoat
Light Source
Tridonic SLE LED
Downloads
Design Features

Recessed lamp for low glare applications
Prismatic optics for even greater glare control
Tool-free interchangeable optics
Tapered ‘knife-edge’ for clean modern aesthetic
90° gimbal inclination
350° rotation
Up to 91 exit lumens per system watt
80+ colour rendering
90+ colour rendering available on request
High colour tolerance Macadam 3
Complies with AS/NZS 60598.2.1
L80 / B10 = 55,000 hours @ 250mA / 65°C TP
L80 / B10 = 55,000 hours @ 350mA / 65°C TP

Installation Features

Track mounted with integrated driver
5 year warranty
10 year extended warranty optional
Project specific labelling referencing type numbers
Easy to follow install guide
Australian designed and assembled
